CMT3501T2

The CMT3501T2 is an ideal single-chip solution for high precision temperature measurement with an I²C interface to provide accurate temperature data. The sensor temperature outputs are digitized by a high resolution 24-bit ADC. Data compensation is integrated internally to save the effort of the external host MCU system.

Description

The CMT3501T2 is an ideal single-chip solution for high precision temperature measurement with an I²C interface to provide accurate temperature data. The sensor temperature outputs are digitized by a high resolution 24-bit ADC. Data compensation is integrated internally to save the effort of the external host MCU system. The temperature value is calculated by a specific compensation algorithm according to the temperature data. Easy command-based data acquisition interface is available.

Features

  • 1.8V to 3.6V Supply Voltage
  • Standby Current Less Than 100 nA
  • Full Data Compensation
  • 20-bit Temperature Measurement (Celsius)
  • Command-based Reading
    • 20-bit Raw Data Output
    • 20-bit Compensated Data Output
  • Configurable ADC Decimation Rate via Commands
  • Temperature Resolution down to 0.01 Celsius
  • High-speed I²C Digital Output Interface (Up to 5 MHz)

Applications

  • Clinical Thermometer
  • Digital Thermometer
  • Water Heater
  • Green Home Appliances
  • Industrial Control
  • Automotive Electronics
  • Environmental Monitoring System
  • Instruments

Description Version Updated Size
CMT3501T2 1.0 2015/05/22 205.98 KB
Description Version Updated Size
Description Version Updated Size

Similar Devices
 Part Number ADC Resolution
(bit)
ENOB
(bit)
 Max DSR Temperature
Range (°C)
Temperature
Resolution (°C)

Order Samples

CMOSTEK provides samples to qualified developers at no charge, please fill the form below to start the application.

 *
 *
 *
 *
 *
 *
 *
 *
 *
 *
 *
    *
